CRYSTAL SUITE LIFT

Complying to AS1735.14 & AS1735.15 – Low rise platforms for passengers & non-automatically controlled limited mobility lift

The sleek and efficient Crystal Suite Lift is the perfect solution for Disability Access. Platinum Elevators has built this package specifically for Victoria. The Crystal Suite platform is perfect for any environment thanks to its sleek and carefully designed configuration, which includes stainless steel frame, toughened safety glass panelling, mechanical guard system, anti-slip aluminium floor, glass doors with semiautomatic closing and electric lock.

Building large ramps for limited mobility access to buildings can be costly with the current gradient required for ramps, the space required can be substantive and not always achievable. The Crystal Suite Lift is the perfect solution for saving space and offers immediate access to any building entrance. Getting your certificate of occupancy is easy when you have a compliant Crystal Suite Lift installed.

SAFETY FEATURES

  • Emergency Battery backup in case of power failure
  • Platform and Landing Door Enabling Keys
  • Braille Push Buttons
TECHNICAL INFORMATION
LIFT CODE AS1735.14
PLATFORM SIZE 1200W - 1600D (mm)
CLEAR DOOR OPENING 900 mm
LOAD RATING 300kg - 400kg
TRAVEL 1m (Max)
PIT 240 mm (Min)
POWER Single Phase 25amp
TECHNICAL INFORMATION
LIFT CODE AS1735.15
PLATFORM SIZE 1200W - 1600D (mm)
CLEAR DOOR OPENING 900 mm
LOAD RATING 300kg - 400kg
TRAVEL 1.6m (Max)
PIT 370 mm (Min)
POWER Single Phase 25amp

COMPLETE DESIGN FLEXIBILITY

If you are building a new home or looking to retrofit a lift into a existing home, Platinum Elevators highly skilled consultants can assist you with design, ideas and concepts to ensure you get the best product in the most suitable location. You will be amazed where we can incorporate a lift into any building design, minimising space and saving on builders works.

Platinum Elevators will custom design the largest possible cabin size to suit any existing shaft or we can customise a Glazed Metal Structure to surround the lift in both indoor or outdoor applications creating a luxurious and state of the art feature.
