Residential Suite Lift
Complying to AS1735.18 Passenger lifts for private residence
The Residential Suite Lift is one of the most attractive and captivating home lifts on the market. Platinum Elevators guarantee a minimum 300kg load rating with every Residential Suite Lift cabin configuration as ‘standard’ making the Residential Suite Lift an industry leading mighty powerful home lift with manual swing landing doors. Platinum Elevators Residential Suite Lift cabin can be completely customised starting from 600x600mm all the way up to 1100x1400mm. Offering complete flexibility with design.
TECHNICAL INFORMATION
LIFT CODE | AS1735.18 |
---|---|
LOAD RATING | 300kg-400kg |
SPEED | 0.30m/s |
TRAVEL | 12m (Max) |
PIT | 120 mm (Min) |
HEADROOM | 2500 mm (Min) |
CONTROL CABINET | 750Wx410Dx1400H (mm) |
POWER | 300kg - Single Phase 25amp 400kg - Single Phase 32amp |

SAFETY FEATURES – PEACE OF MIND
- Battery backup and Cabin lighting in case of power failure
- Automatic return to lowest floor
- Full height light curtain protection beams across cabin entrance
- Over Load Alarm and Indicator
- Creeping Speed Feature
EACH RESIDENTIAL SUITE LIFT PACKAGE COMES WITH THE FOLLOWING INCLUSIONS AS STANDARD:
COMPLETE DESIGN FLEXIBILITY
If you are building a new home or looking to retrofit a lift into an existing home, Platinum Elevators highly skilled consultants can assist you with ideas, design and concepts to ensure you get the best Residential Suite lift in the most aesthetically suitable location. You will be amazed where we can incorporate a home lift into any building design, minimising space and saving on builders works.
Platinum Elevators will custom design the largest possible Residential Suite Lift cabin size to suit any existing shaft or we can customise a Glazed Metal Structure to surround the lift in either indoor or outdoor applications, creating a luxury elevator and state-of-the-art feature.
