COMMERCIAL CROWN SUITE LIFT

Complying to AS1735.1 / 12 General Passenger Lift

The Commercial Crown Suite Lift package is designed specifically for Commercial and Public applications. This Lift comes with all the requirements of AS1735.1 / 12 and is Design Registered with WorkSafe.

Complying with the Building Code of Australia (BCA) and the DDA for Limited Mobility.

Platinum Elevators have carefully designed a complete package for every Commercial Crown Suite Lift as “standard” making the Commercial Crown Suite Lift an extremely reliable General Passenger lift with automatic sliding cabin and landing doors. This commercial lift package is industry leading with many inclusions and technology comforts for the users.

TECHNICAL INFORMATION
LIFT CODE AS1735.1/12
LOAD RATING 630kg
SPEED 0.60m/s
TRAVEL 18m (Max)
PIT 1300 mm (Min)
HEADROOM 3300 mm (Min)
CONTROL CABINET 810Wx400Dx2050H (mm)
POWER Three Phase 415V
Residential suite lift

INCLUDED FEATURES

  • Cabin and Landing Door Enabling Keys
  • Auto Dial Telephone in Cabin
  • Brushed Stainless Steel Handrail
  • Brushed Stainless Steel Cabin and Landing Doors and Frames
  • All Push Buttons with Braille
  • No lifting beams required in shaft

SAFETY FEATURES – PEACE OF MIND

  • Battery backup and Cabin lighting in case of power failure
  • Automatic return to lowest floor
  • Full height light curtain protection beams across cabin entrance
  • Over Load Alarm and Indicator
  • Creeping Speed Feature

EACH COMMERCIAL CROWN SUITE LIFT PACKAGE COMES WITH THE FOLLOWING INCLUSIONS AS STANDARD:

Z

Digital Cabin Display

Z

4 x LED Ceiling Lights

Z

Dual Full Height Control Operating Panels with Sleek Button Integration Design

Z

Stylish Push Buttons with Braile

Z

Wide Range of Luxury Skinplate Wall Finishes

Z

Cabin and Landing Door Enabling Keys

Z

Stainless Steel Handrail

Z

Brushed Stainless Steel Cabin and Landing Doors

COMPLETE DESIGN FLEXIBILITY

Whether it’s for a new commercial build or looking to retrofit a commercial lift into an existing building, Platinum Elevators highly skilled consultants can assist you with design, ideas and concepts to ensure you get the correct product designed for the right application and complying with all current Australian commercial lift regulations. You will be amazed where we can incorporate a Commercial CROWN Suite Lift into any building design, minimising space and saving on unnecessary builders works.

Platinum Elevators will custom design the largest possible cabin size to suit any existing shaft or we can customise a Glazed Metal Structure Shaft to surround the Commercial Suite Lift in both indoor and outdoor applications. The Commercial CROWN Suite Lift by Platinum Elevators is an industry leading General Passenger Lift with reliability by design.

Manufacturing Your Suite Lift

Virtual Cabin Tour

View a Recent Project

Client: Probuild
Location: Eastland Shopping Centre (Ringwood) VIC

Platinum Elevators were able to meet a very tight schedule by working out of normal hours. The installation staff were very professional and friendly. Will certainly recommend you on future projects.

Mr Bullen – East Land Shopping Centre Project Manager

Enquire About the Commercial Crown Suite Lift Today
